NJW4140RZ2-TE1
IC REG BST FLYBCK ADJ 8VSPManufacturer: Nisshinbo Micro Devices Inc.
Categories: DC DC Switching Regulators
Quality Control: Learn More
Nisshinbo Micro Devices Inc. NJW4140RZ2-TE1, an automotive-grade boost and flyback switching regulator, offers adjustable positive output voltage from 0.8V up to 40V. This versatile device supports input voltages ranging from 3V to 40V, with a switching frequency adjustable between 40kHz and 1MHz. Designed for surface mounting, it is housed in an 8-VSP package, specifically an 8-LSSOP, 8-MSOP (0.110", 2.80mm Width). The NJW4140RZ2-TE1 operates across an extended temperature range of -40°C to 125°C and is AEC-Q100 qualified. Its functionality as a step-up or step-up/step-down regulator makes it suitable for applications in automotive and industrial power management systems. The component is supplied in a Tape & Reel (TR) package.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 26 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-LSSOP, 8-MSOP (0.110"", 2.80mm Width) |
| Output Type | Adjustable |
| Mounting Type | Surface Mount |
| Number of Outputs | 1 |
| Function | Step-Up, Step-Up/Step-Down |
| Current - Output | - |
| Operating Temperature | -40°C ~ 125°C |
| Output Configuration | Positive |
| Frequency - Switching | 40kHz ~ 1MHz |
| Voltage - Input (Max) | 40V |
| Topology | Boost, Flyback |
| Supplier Device Package | 8-VSP |
| Synchronous Rectifier | No |
| Voltage - Output (Max) | 40V |
| Voltage - Input (Min) | 3V |
| Voltage - Output (Min/Fixed) | 0.8V |
| Grade | Automotive |
| Qualification | AEC-Q100 |
