NJW4132U2-A-TE2
IC REG BOOST ADJ 2.25A SOT89-5Manufacturer: Nisshinbo Micro Devices Inc.
Categories: DC DC Switching Regulators
Quality Control: Learn More
The Nisshinbo Micro Devices Inc. NJW4132U2-A-TE2 is a positive adjustable boost switching regulator designed for efficient step-up voltage conversion. This component delivers a maximum output current of 2.25A and operates at a switching frequency of 300kHz. It accepts input voltages ranging from 4.5V to 40V, with a configurable output voltage settable from 1V up to 40V. The NJW4132U2-A-TE2 utilizes a non-synchronous boost topology and is housed in a SOT-89-5/6 surface-mount package. Its operating temperature range is -40°C to 85°C, making it suitable for applications in consumer electronics, industrial automation, and battery-powered devices.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: 26 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | SOT-89-5/6 |
| Output Type | Adjustable |
| Mounting Type | Surface Mount |
| Number of Outputs | 1 |
| Function | Step-Up |
| Current - Output | 2.25A |
| Operating Temperature | -40°C ~ 85°C |
| Output Configuration | Positive |
| Frequency - Switching | 300kHz |
| Voltage - Input (Max) | 40V |
| Topology | Boost |
| Supplier Device Package | SOT-89-5 |
| Synchronous Rectifier | No |
| Voltage - Output (Max) | 40V |
| Voltage - Input (Min) | 4.5V |
| Voltage - Output (Min/Fixed) | 1V |
