NJM360M
IC COMPARATOR 1 DIFF 8DMPManufacturer: Nisshinbo Micro Devices Inc.
Categories: Comparators
Quality Control: Learn More
The Nisshinbo Micro Devices Inc. NJM360M is a high-performance differential comparator designed for demanding applications. This single-element device features complementary, TTL-compatible outputs and a surface-mount 8-SOIC package. With a typical input bias current of 20µA and an output current capability of 20mA, it offers robust performance. The NJM360M operates over a temperature range of -40°C to 85°C and supports dual supply voltages from ±4.5V to ±6.5V. Its differential input design and the 8-DMP supplier device package make it suitable for use in various industrial and consumer electronics sectors.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDownload Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 8-SOIC (0.209"", 5.30mm Width) |
| Output Type | Complementary, TTL |
| Mounting Type | Surface Mount |
| Number of Elements | 1 |
| Type | Differential |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply, Single/Dual (±) | ±4.5V ~ 6.5V |
| Supplier Device Package | 8-DMP |
| Propagation Delay (Max) | - |
| Current - Quiescent (Max) | 32mA |
| Voltage - Input Offset (Max) | 5mV |
| Current - Input Bias (Max) | 20µA |
| Current - Output (Typ) | 20mA |
| CMRR, PSRR (Typ) | - |
| Hysteresis | - |
