NJU201AD
IC SWITCH SPST-NCX4 100OHM 16DIPManufacturer: Nisshinbo Micro Devices Inc.
Categories: Analog Switches, Multiplexers, Demultiplexers
Quality Control: Learn More
Nisshinbo Micro Devices Inc. NJU201AD is a 4-circuit SPST-NC analog switch. This component features a 1:1 multiplexer/demultiplexer circuit configuration with a maximum on-state resistance of 100 Ohms. It operates with dual supply voltages up to ±15V and has a charge injection of 20pC. The crosstalk is specified at -90dB at 100kHz, and the leakage current (IS(off)) is a maximum of 100nA. Channel capacitance is 5pF for both CS(off) and CD(off). Switching times are 600ns for turn-on and 450ns for turn-off. The NJU201AD is supplied in a 16-DIP (0.300", 7.62mm) through-hole package, suitable for applications in consumer electronics and industrial control systems. It operates within a temperature range of 0°C to 70°C.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: 26 week(s)Product Status: Last Time BuyPackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 16-DIP (0.300"", 7.62mm) |
| Mounting Type | Through Hole |
| Operating Temperature | 0°C ~ 70°C (TA) |
| On-State Resistance (Max) | 100Ohm |
| -3db Bandwidth | - |
| Supplier Device Package | 16-DIP |
| Voltage - Supply, Single (V+) | - |
| Voltage - Supply, Dual (V±) | ±15V |
| Charge Injection | 20pC |
| Crosstalk | -90dB @ 100kHz |
| Switch Circuit | SPST - NC |
| Multiplexer/Demultiplexer Circuit | 1:1 |
| Channel-to-Channel Matching (ÃŽ”Ron) | - |
| Switch Time (Ton, Toff) (Max) | 600ns, 450ns |
| Channel Capacitance (CS(off), CD(off)) | 5pF, 5pF |
| Current - Leakage (IS(off)) (Max) | 100nA |
| Number of Circuits | 4 |
