PZU4.3DB2,115
DIODE ZENER ARRAY 4.3V 5TSSOPManufacturer: Nexperia USA Inc.
Categories: Zener Diode Arrays
Quality Control: Learn More
Nexperia USA Inc. offers the PZU4-3DB2-115, a Zener Diode Array designed for precision voltage regulation. This component features two independent 4.3 V Zener diodes, each rated for 250 mW power dissipation with a tight ±2% tolerance. The array is housed in a compact 5-TSSOP (SC-70-5, SOT-353) package, suitable for surface mount applications. Key electrical characteristics include a low reverse leakage of 3 µA at 1 V and a maximum Zener impedance (Zzt) of 90 Ohms. The forward voltage (Vf) is 900 mV at 10 mA. Operating across a wide temperature range of -55°C to 150°C, this device finds application in telecommunications and consumer electronics where stable voltage references are critical. The PZU4-3DB2-115 is supplied in Tape & Reel packaging.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Tolerance | ±2% |
| Packaging | Tape & Reel (TR) |
| Package / Case | 5-TSSOP, SC-70-5, SOT-353 |
| Mounting Type | Surface Mount |
| Configuration | 2 Independent |
| Operating Temperature | -55°C ~ 150°C |
| Voltage - Zener (Nom) (Vz) | 4.3 V |
| Impedance (Max) (Zzt) | 90 Ohms |
| Supplier Device Package | 5-TSSOP |
| Power - Max | 250 mW |
| Voltage - Forward (Vf) (Max) @ If | 900 mV @ 10 mA |
| Current - Reverse Leakage @ Vr | 3 µA @ 1 V |
Request a Quote
