PSMN075-100MSEX
MOSFET N-CH 100V 18A LFPAK33Manufacturer: Nexperia USA Inc.
Categories: Single FETs, MOSFETs
Quality Control: Learn More
N-Channel 100 V 18A (Tj) 65W (Tc) Surface Mount LFPAK33
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 13 week(s)Product Status: ActivePackaging: Digi-Reel®Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Digi-Reel® |
| Package / Case | SOT-1210, 8-LFPAK33 (5-Lead) |
| Mounting Type | Surface Mount |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Technology | MOSFET (Metal Oxide) |
| FET Type | N-Channel |
| Current - Continuous Drain (Id) @ 25°C | 18A (Tj) |
| Rds On (Max) @ Id, Vgs | 71mOhm @ 5A, 10V |
| FET Feature | - |
| Power Dissipation (Max) | 65W (Tc) |
| Vgs(th) (Max) @ Id | 4V @ 1mA |
| Supplier Device Package | LFPAK33 |
| Drive Voltage (Max Rds On, Min Rds On) | 10V |
| Vgs (Max) | ±20V |
| Drain to Source Voltage (Vdss) | 100 V |
| Gate Charge (Qg) (Max) @ Vgs | 16.4 nC @ 10 V |
| Input Capacitance (Ciss) (Max) @ Vds | 773 pF @ 50 V |
