BSH103,215
MOSFET N-CH 30V 850MA TO236ABManufacturer: Nexperia USA Inc.
Categories: Single FETs, MOSFETs
Quality Control: Learn More
The Nexperia BSH103-215 is a surface-mount N-Channel MOSFET housed in a TO-236AB (SC-59) package. This device features a Drain-Source Voltage (Vdss) of 30V and a continuous Drain Current (Id) of 850mA at 25°C ambient. With a maximum On-Resistance (Rds On) of 400mOhm at 500mA and 4.5V Vgs, it offers efficient switching. The gate threshold voltage (Vgs(th)) is a nominal 400mV at 1mA. Input capacitance (Ciss) is rated at 83pF maximum at 24V, with a gate charge (Qg) of 2.1nC at 4.5V. Power dissipation is 540mW ambient. Operating temperature range is -55°C to 150°C. This component is commonly utilized in consumer electronics and industrial applications requiring compact, efficient switching solutions. It is supplied on Tape & Reel.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 6 week(s)Product Status: Not For New DesignsPackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | TO-236-3, SC-59, SOT-23-3 |
| Mounting Type | Surface Mount |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Technology | MOSFET (Metal Oxide) |
| FET Type | N-Channel |
| Current - Continuous Drain (Id) @ 25°C | 850mA (Ta) |
| Rds On (Max) @ Id, Vgs | 400mOhm @ 500mA, 4.5V |
| FET Feature | - |
| Power Dissipation (Max) | 540mW (Ta) |
| Vgs(th) (Max) @ Id | 400mV @ 1mA (Min) |
| Supplier Device Package | TO-236AB |
| Drive Voltage (Max Rds On, Min Rds On) | 2.5V |
| Vgs (Max) | ±8V |
| Drain to Source Voltage (Vdss) | 30 V |
| Gate Charge (Qg) (Max) @ Vgs | 2.1 nC @ 4.5 V |
| Input Capacitance (Ciss) (Max) @ Vds | 83 pF @ 24 V |
