PMEG3010EB,115
DIODE SCHOTTKY 30V 1A SOD523Manufacturer: Nexperia USA Inc.
Categories: Single Diodes
Quality Control: Learn More
Diode 30 V 1A Surface Mount SOD-523
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 8 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | SC-79, SOD-523 |
| Mounting Type | Surface Mount |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Technology | Schottky |
| Capacitance @ Vr, F | 30pF @ 1V, 1MHz |
| Current - Average Rectified (Io) | 1A |
| Supplier Device Package | SOD-523 |
| Operating Temperature - Junction | 150°C (Max) |
| Grade | Automotive |
| Voltage - DC Reverse (Vr) (Max) | 30 V |
| Voltage - Forward (Vf) (Max) @ If | 680 mV @ 1 A |
| Current - Reverse Leakage @ Vr | 500 µA @ 30 V |
| Qualification | AEC-Q101 |
