BC817-40/SNR
TRANS NPN 45V 0.5A TO236ABManufacturer: Nexperia USA Inc.
Categories: Single Bipolar Transistors
Quality Control: Learn More
Nexperia USA Inc. BC817-40-SNR is a bipolar junction transistor (BJT) of NPN type. This component features a collector-emitter breakdown voltage (Vceo) of 45V and a continuous collector current (Ic) capability of 500mA. The specified DC current gain (hFE) is a minimum of 250 at 100mA collector current and 1V collector-emitter voltage. With a transition frequency of 100MHz and a maximum power dissipation of 250mW, this device is suitable for general-purpose amplification and switching applications. The Vce(sat) is specified at 700mV maximum for a base current of 50mA and collector current of 500mA. This transistor is provided in a TO-236AB (SC-59) surface mount package, supplied on tape and reel. Its operating junction temperature range extends to 150°C. Applications include consumer electronics and industrial control systems.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | TO-236-3, SC-59, SOT-23-3 |
| Mounting Type | Surface Mount |
| Transistor Type | NPN |
| Operating Temperature | 150°C (TJ) |
| Vce Saturation (Max) @ Ib, Ic | 700mV @ 50mA, 500mA |
| Current - Collector Cutoff (Max) | 100nA (ICBO) |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 250 @ 100mA, 1V |
| Frequency - Transition | 100MHz |
| Supplier Device Package | TO-236AB |
| Current - Collector (Ic) (Max) | 500 mA |
| Voltage - Collector Emitter Breakdown (Max) | 45 V |
| Power - Max | 250 mW |
