BC817-25W/MIX
TRANS NPN 45V 0.5A SOT323Manufacturer: Nexperia USA Inc.
Categories: Single Bipolar Transistors
Quality Control: Learn More
Nexperia BC817-25W-MIX is an NPN bipolar junction transistor (BJT) designed for surface mount applications. This component features a collector-emitter breakdown voltage of 45V and a maximum continuous collector current of 500mA. The transistor exhibits a minimum DC current gain (hFE) of 160 at 100mA and 1V, with a transition frequency of 100MHz. Its maximum power dissipation is rated at 200mW. The device is housed in a SOT-323 (SC-70) package and is supplied in tape and reel. Qualifying for AEC-Q101, this transistor is suitable for automotive applications. It operates within a temperature range of 150°C (TJ).
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | SC-70, SOT-323 |
| Mounting Type | Surface Mount |
| Transistor Type | NPN |
| Operating Temperature | 150°C (TJ) |
| Vce Saturation (Max) @ Ib, Ic | 700mV @ 50mA, 500mA |
| Current - Collector Cutoff (Max) | 100nA (ICBO) |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 160 @ 100mA, 1V |
| Frequency - Transition | 100MHz |
| Supplier Device Package | SOT-323 |
| Grade | Automotive |
| Current - Collector (Ic) (Max) | 500 mA |
| Voltage - Collector Emitter Breakdown (Max) | 45 V |
| Power - Max | 200 mW |
| Qualification | AEC-Q101 |
