LD6805K/33H,115
NEXPERIA LD6805K/33H - FIXED POSManufacturer: Nexperia USA Inc.
Categories: Linear, Low Drop Out (LDO) Regulators
Quality Control: Learn More
Nexperia LD6805K-33H-115 is a fixed positive linear voltage regulator offering a 3.3V output with a 150mA current capability. This device features a low dropout voltage of 0.25V at 150mA, ensuring efficient operation even with minimal input-output voltage difference. The LD6805K-33H-115 includes over-current and transient voltage protection for robust system performance. With an input voltage range up to 5.5V, it is suitable for applications requiring stable power delivery in portable electronics, industrial control, and telecommunications infrastructure. The compact DFN1010C-4 package with an exposed pad facilitates thermal management for surface-mount assembly. The regulator incorporates an enable pin for power sequencing and control. Its high Power Supply Rejection Ratio (PSRR) of 75dB at 1kHz minimizes noise coupling from the input supply.
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 4-UDFN Exposed Pad |
| Output Type | Fixed |
| Mounting Type | Surface Mount |
| Current - Output | 150mA |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Output Configuration | Positive |
| Voltage - Input (Max) | 5.5V |
| Number of Regulators | 1 |
| Supplier Device Package | DFN1010C-4 |
| Voltage - Output (Max) | - |
| Voltage - Output (Min/Fixed) | 3.3V |
| Control Features | Enable |
| PSRR | 75dB (1kHz) |
| Voltage Dropout (Max) | 0.25V @ 150mA |
| Protection Features | Over Current, Transient Voltage |
