74HCT4067DB,118
IC MUX 16:1 120OHM 24SSOPManufacturer: Nexperia USA Inc.
Categories: Analog Switches, Multiplexers, Demultiplexers
Quality Control: Learn More
Nexperia USA Inc. 74HCT4067DB-118 is a 16:1 multiplexer/demultiplexer featuring a 4.5V to 5.5V single supply operation. This analog switch IC offers a low ON-state resistance of 120 Ohms maximum, with channel-to-channel matching (?Ron) of 6 Ohms. Its -3dB bandwidth extends to 100MHz, supporting signal integrity in demanding applications. The device exhibits a typical channel capacitance of 3.5pF and a leakage current (IS(off)) of 800nA maximum. Switching times are rated at 65ns for turn-on and 60ns for turn-off. Packaged in a 24-SSOP for surface mounting, the 74HCT4067DB-118 operates across a temperature range of -40°C to 125°C. This component is suitable for applications in industrial automation, consumer electronics, and automotive systems.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 24-SSOP (0.209"", 5.30mm Width) |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 125°C (TA) |
| On-State Resistance (Max) | 120Ohm |
| -3db Bandwidth | 100MHz |
| Supplier Device Package | 24-SSOP |
| Voltage - Supply, Single (V+) | 4.5V ~ 5.5V |
| Voltage - Supply, Dual (V±) | - |
| Charge Injection | - |
| Crosstalk | - |
| Switch Circuit | - |
| Multiplexer/Demultiplexer Circuit | 16:1 |
| Channel-to-Channel Matching (ÃŽ”Ron) | 6Ohm |
| Switch Time (Ton, Toff) (Max) | 65ns, 60ns |
| Channel Capacitance (CS(off), CD(off)) | 3.5pF |
| Current - Leakage (IS(off)) (Max) | 800nA |
| Number of Circuits | 1 |
