NHD-0420DZ-FSW-GBW
LCD MOD 80DIG 20X4 TRANSFLCT WHTManufacturer: Newhaven Display Intl
Categories: LCD, OLED Character and Numeric
Quality Control: Learn More
Newhaven Display Intl NHD-0420DZ-FSW-GBW is a 20x4 character LCD module featuring a transflective STN display with white LED backlight. This module supports an 80-character display, with each character configured as a 5x8 dot matrix. The operating temperature range is -20°C to 70°C and it requires a 5V supply voltage. The overall module dimensions are 98.00mm x 60.00mm x 14.00mm, with a viewing area of 76.00mm x 25.20mm. This component is suitable for applications in industrial control, instrumentation, and point-of-sale systems where reliable alphanumeric display is critical.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BoxDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Box |
| Display Type | STN - Super-Twisted Nematic |
| Display Mode | Transflective |
| Backlight | LED - White |
| Interface | - |
| Operating Temperature | -20°C ~ 70°C |
| Voltage - Supply | 5V |
| Viewing Area | 76.00mm L x 25.20mm W |
| Character Size | 4.75mm H x 2.95mm W |
| Display Format | 20 x 4 |
| Character Format | 5 x 8 Dots |
| Dot Size | 0.55mm W x 0.55mm H |
| Outline L x W x H | 98.00mm x 60.00mm x 14.00mm |
| Text Color | - |
| Background Color | - |
| Number of Characters | 80.0 |
