NHD-0416B1Z-FSPG-YBW-L-3V
LCD MOD 64DIG 16X4 TRANSFLCT GRNManufacturer: Newhaven Display Intl
Categories: LCD, OLED Character and Numeric
Quality Control: Learn More
Newhaven Display Intl NHD-0416B1Z-FSPG-YBW-L-3V is a 16x4 character LCD module featuring a transflective STN display with green LED backlighting. This module offers 64 characters with a 5x8 dot matrix format, providing a character size of 4.75mm H x 2.95mm W. The dot size is 0.55mm W x 0.55mm H. It utilizes a parallel interface for data and control. The operating temperature range is -20°C to 70°C, and it requires a supply voltage of 3.2V to 3.4V. The module's outline dimensions are 87.00mm x 60.00mm x 14.00mm, with a viewing area of 61.80mm L x 25.20mm W. This component is commonly employed in industrial automation, medical devices, and point-of-sale systems.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BoxDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Box |
| Display Type | STN - Super-Twisted Nematic |
| Display Mode | Transflective |
| Backlight | LED - Green |
| Interface | Parallel |
| Operating Temperature | -20°C ~ 70°C |
| Voltage - Supply | 3.2V ~ 3.4V |
| Viewing Area | 61.80mm L x 25.20mm W |
| Character Size | 4.75mm H x 2.95mm W |
| Display Format | 16 x 4 |
| Character Format | 5 x 8 Dots |
| Dot Size | 0.55mm W x 0.55mm H |
| Outline L x W x H | 87.00mm x 60.00mm x 14.00mm |
| Text Color | - |
| Background Color | Green |
| Number of Characters | 64.0 |
