CLC5665IMX
IC OPAMP CFA 1 CIRCUIT 8SOICManufacturer: National Semiconductor
Categories: Instrumentation, Op Amps, Buffer Amps
Quality Control: Learn More
The National Semiconductor CLC5665IMX is a high-performance current feedback amplifier designed for demanding applications. This single-circuit device features a substantial -3dB bandwidth of 90 MHz and an impressive slew rate of 1800V/µs, enabling rapid signal processing. With a low input bias current of 3 µA and a typical supply current of 11 mA, it offers efficient operation within a broad supply voltage range of 10 V to 30 V. The CLC5665IMX is housed in an 8-SOIC package, suitable for surface mounting. Its robust specifications make it a reliable component for use in instrumentation and buffering applications across various industrial sectors. The device operates effectively within an ambient temperature range of -40°C to 85°C.
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 8-SOIC (0.154"", 3.90mm Width) |
| Output Type | - |
| Mounting Type | Surface Mount |
| Amplifier Type | Current Feedback |
| Operating Temperature | -40°C ~ 85°C |
| Current - Supply | 11mA |
| Slew Rate | 1800V/µs |
| Current - Input Bias | 3 µA |
| Voltage - Input Offset | 15 mV |
| Supplier Device Package | 8-SOIC |
| Number of Circuits | 1 |
| -3db Bandwidth | 90 MHz |
| Voltage - Supply Span (Min) | 10 V |
| Voltage - Supply Span (Max) | 30 V |
