LM5035SQ/NOPB
LM5035 PWM CONTROLLER WITH INTEGManufacturer: National Semiconductor
Categories: DC DC Switching Controllers
Quality Control: Learn More
Half-Bridge Regulator Positive, Isolation Capable Output Step-Up/Step-Down DC-DC Controller IC 24-WQFN (4x5)
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ActivePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 24-WFQFN Exposed Pad |
| Output Type | Transistor Driver |
| Mounting Type | Surface Mount |
| Function | Step-Up/Step-Down |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Output Configuration | Positive, Isolation Capable |
| Frequency - Switching | 200kHz, 500kHz |
| Topology | Half-Bridge |
| Voltage - Supply (Vcc/Vdd) | 13V ~ 105V |
| Supplier Device Package | 24-WQFN (4x5) |
| Synchronous Rectifier | Yes |
| Control Features | Frequency Control, Ramp, Soft Start |
| Serial Interfaces | - |
| Output Phases | 1 |
| Duty Cycle (Max) | - |
| Clock Sync | Yes |
| Number of Outputs | 1 |
