LMV7251M5
IC COMPARATOR 1 GEN PUR SOT23-5Manufacturer: National Semiconductor
Categories: Comparators
Quality Control: Learn More
The National Semiconductor LMV7251M5 is a single-channel, general-purpose comparator designed for robust performance in demanding applications. Featuring rail-to-rail output and a push-pull configuration, this device offers efficient signal interfacing. Its low input bias current, specified at a maximum of 0.016µA at 5V, and a quiescent current of 20µA (max), contribute to power-efficient designs. The LMV7251M5 operates across a wide supply voltage range of 1.8V to 5V and supports a typical output current of 82mA at 5V. With excellent Common Mode Rejection Ratio (CMRR) and Power Supply Rejection Ratio (PSRR) of 72dB and 79dB respectively, it ensures signal integrity in noisy environments. The LMV7251M5 is suitable for use in automotive, industrial, and consumer electronics sectors. It is supplied in a SOT-23-5 package for surface mounting.
Additional Information
Series: -RoHS Status: RoHS Compliant By ExemptionManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | SC-74A, SOT-753 |
| Output Type | Push-Pull, Rail-to-Rail |
| Mounting Type | Surface Mount |
| Number of Elements | 1 |
| Type | General Purpose |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply, Single/Dual (±) | 1.8V ~ 5V |
| Supplier Device Package | SOT-23-5 |
| Propagation Delay (Max) | 830ns |
| Current - Quiescent (Max) | 20µA |
| Voltage - Input Offset (Max) | 6mV @ 5V |
| Current - Input Bias (Max) | 0.016µA @ 5V |
| Current - Output (Typ) | 82mA @ 5V |
| CMRR, PSRR (Typ) | 72dB, 79dB |
| Hysteresis | - |
