CLC016AJQ/NOPB
IC PHASE LOCK LOOP 28PLCCManufacturer: National Semiconductor
Categories: Clock Generators, PLLs, Frequency Synthesizers
Quality Control: Learn More
National Semiconductor CLC016AJQ-NOPB is a Phase Lock Loop (PLL) integrated circuit designed for precise clock generation and distribution. This single-circuit device features ECL and PECL compatible inputs and outputs, facilitating high-speed signal integrity. The CLC016AJQ-NOPB offers a 1:2 ratio for input to output division, supporting applications requiring frequency manipulation within clock systems. It is housed in a 28-PLCC (J-Lead) surface-mount package, suitable for robust PCB assembly. Operating within a temperature range of -40°C to 85°C and requiring a supply voltage of 4.5V to 5.5V, this component is engineered for demanding environments. Its differential input/output capabilities further enhance its utility in high-frequency signal processing. This component finds application in telecommunications, broadcast video, and other high-speed digital systems where accurate clock synchronization is critical.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | 28-LCC (J-Lead) |
| Mounting Type | Surface Mount |
| Output | ECL, PECL |
| Frequency - Max | - |
| Type | Phase Lock Loop (PLL) |
| Input | ECL, PECL |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 4.5V ~ 5.5V |
| Ratio - Input:Output | 1:2 |
| Differential - Input:Output | Yes/Yes |
| Supplier Device Package | 28-PLCC (11.43x11.43) |
| PLL | Yes |
| Divider/Multiplier | No/No |
| Number of Circuits | 1 |
| Programmable | Not Verified |
