NMT0572SC
DC DC CNVRTR -24V -48V -72V 3WManufacturer: Murata Power Solutions Inc.
Categories: DC DC Converters
Quality Control: Learn More
Murata Power Solutions Inc. NMT (3W) series NMT0572SC is a 3W isolated module DC-DC converter with three negative outputs: -24V at 42mA, -48V at 21mA, and -72V at 14mA. This converter operates from a 4.5V to 5.5V input voltage range, featuring an efficiency of 85% and an isolation voltage of 1 kV. The NMT0572SC is housed in an 8-SIP module with 6 leads and is designed for through-hole mounting. Its compact dimensions are 0.86 inches long by 0.30 inches wide by 0.44 inches high (21.8mm x 7.6mm x 11.2mm). This component is suitable for applications in the ITE (Commercial) industry and operates within an ambient temperature range of -40°C to 85°C.
Additional Information
Series: NMT (3W)RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tube |
| Package / Case | 8-SIP Module, 6 Leads |
| Size / Dimension | 0.86"" L x 0.30"" W x 0.44"" H (21.8mm x 7.6mm x 11.2mm) |
| Mounting Type | Through Hole |
| Type | Isolated Module |
| Operating Temperature | -40°C ~ 85°C |
| Applications | ITE (Commercial) |
| Voltage - Input (Max) | 5.5V |
| Efficiency | 85% |
| Current - Output (Max) | 42mA, 21mA, 14mA |
| Voltage - Input (Min) | 4.5V |
| Voltage - Output 1 | -24V |
| Voltage - Output 2 | -48V |
| Voltage - Output 3 | -72V |
| Power (Watts) | 3 W |
| Number of Outputs | 3 |
| Voltage - Isolation | 1 kV |
