DLW44SM242SK2L
CMC 1.4A 2LN 2.4KOHM SMDManufacturer: Murata Electronics
Categories: Common Mode Chokes
Quality Control: Learn More
Murata Electronics DLW44SM242SK2L is a 2-line surface mount common mode choke from the DLW44 series. This component offers an impedance of 2.4 kOhms at 100 MHz and a maximum continuous current rating of 1.4A. It features a low DC resistance of 105mOhm and a DC voltage rating of 60V. The device is designed for power line filtering applications and operates within a temperature range of -40°C to 105°C. Its compact dimensions of 4.00mm L x 4.00mm W and a maximum height of 1.50mm, along with the horizontal 4 PC Pad package, facilitate efficient board space utilization. This component is commonly employed in automotive and industrial systems for noise suppression. It is supplied on tape and reel.
Additional Information
Series: DLW44RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | Horizontal, 4 PC Pad |
| Filter Type | Power Line |
| Size / Dimension | 0.157"" L x 0.157"" W (4.00mm x 4.00mm) |
| Mounting Type | Surface Mount |
| Number of Lines | 2 |
| Operating Temperature | -40°C ~ 105°C |
| Height (Max) | 0.059"" (1.50mm) |
| Voltage Rating - DC | 60V |
| Current Rating (Max) | 1.4A |
| DC Resistance (DCR) (Max) | 105mOhm |
| Impedance @ Frequency | 2.4 kOhms @ 100 MHz |
