GNM1M2R71E103MA01D
CAP ARRAY 10000PF 25V X7R 0504Manufacturer: Murata Electronics
Categories: Capacitor Networks, Arrays
Quality Control: Learn More
Murata Electronics GNM series GNM1M2R71E103MA01D is a 0504 (1410 Metric) surface mount capacitor array featuring two isolated 10000pF capacitors. Each capacitor is rated for 25V with a ±20% tolerance and utilizes an X7R dielectric material. The component dimensions are 0.054" L x 0.039" W (1.37mm x 1.00mm) with a maximum seated height of 0.031" (0.80mm). This device is supplied in cut tape packaging. The GNM series capacitor arrays are frequently employed in automotive, industrial, and consumer electronics applications requiring space-saving and high-performance capacitor solutions.
Additional Information
Series: GNMRoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Cut Tape (CT)Datasheet:Download Free CAD Model:
Technical Details:
| Tolerance | ±20% |
| Packaging | Cut Tape (CT) |
| Circuit Type | Isolated |
| Capacitance | 10000pF |
| Package / Case | 0504 (1410 Metric) |
| Temperature Coefficient | X7R |
| Size / Dimension | 0.054"" L x 0.039"" W (1.37mm x 1.00mm) |
| Mounting Type | Surface Mount |
| Ratings | - |
| Dielectric Material | Ceramic |
| Supplier Device Package | 0405 (1012 Metric) |
| Height - Seated (Max) | 0.031"" (0.80mm) |
| Voltage - Rated | 25 V |
| Number of Capacitors | 2 |
Request a Quote
Clients Also Buy
NFA31CC470S1E4D
