SCA1020-D06-1
ACCEL 1.7G ANALOG/SPI 12SMDManufacturer: Murata Electronics
Categories: Accelerometers
Quality Control: Learn More
Murata Electronics SCA1020 series accelerometer, part number SCA1020-D06-1. This AEC-Q100 qualified component provides dual-axis (Y, Z) acceleration sensing with a selectable ±1.7g range. It offers both analog and SPI digital output interfaces, with analog sensitivity rated at 1200 mV/g. The device features a 50Hz bandwidth and operates from a 5V supply. Designed for surface mount applications, it is supplied in a 12-SMD gull wing package, presented on tape and reel. This accelerometer is suitable for demanding automotive applications requiring robust and precise motion detection.
Additional Information
Series: SCA1020RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tape & Reel (TR) |
| Package / Case | 12-SMD, Gull Wing |
| Output Type | Analog, SPI |
| Mounting Type | Surface Mount |
| Type | Analog, Digital |
| Axis | Y, Z |
| Acceleration Range | ±1.7g |
| Operating Temperature | - |
| Voltage - Supply | 5V |
| Bandwidth | 50Hz |
| Supplier Device Package | 12-SMD |
| Sensitivity (LSB/g) | - |
| Sensitivity (mV/g) | 1200 |
| Grade | Automotive |
| Qualification | AEC-Q100 |
