TD041S485H
IC TRANSCEIVER HALF 1/1 16DFNManufacturer: Mornsun America, LLC
Categories: Drivers, Receivers, Transceivers
Quality Control: Learn More
Mornsun America, LLC TD041S485H is a half-duplex RS485 transceiver supporting a 1Mbps data rate. This component features a single driver and single receiver configuration, housed in a 16-DFN (10x10) surface-mount package supplied on tape and reel. Operating over an extended temperature range of -40°C to 105°C, it is designed for applications requiring robust serial communication. Key specifications include a supply voltage range of 2.375V and 4.5V to 5.5V, and a receiver hysteresis of 20mV, contributing to reliable signal integrity in noisy environments. This transceiver is suitable for industrial automation, telecommunications, and building control systems.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: Product Status: Not For New DesignsPackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 16-DFN |
| Mounting Type | Surface Mount |
| Type | Transceiver |
| Operating Temperature | -40°C ~ 105°C (TA) |
| Voltage - Supply | 2.375V, 4.5V ~ 5.5 V |
| Number of Drivers/Receivers | 1/1 |
| Data Rate | 1Mbps |
| Protocol | RS485 |
| Supplier Device Package | 16-DFN (10x10) |
| Receiver Hysteresis | 20 mV |
| Duplex | Half |
