MP8102DJ-LF-Z
IC OPAMP GP 1 CIRCUIT TSOT23-5Manufacturer: Monolithic Power Systems Inc.
Categories: Instrumentation, Op Amps, Buffer Amps
Quality Control: Learn More
General Purpose Amplifier 1 Circuit Rail-to-Rail TSOT-23-5
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | SOT-23-5 Thin, TSOT-23-5 |
| Output Type | Rail-to-Rail |
| Mounting Type | Surface Mount |
| Amplifier Type | General Purpose |
| Operating Temperature | -40°C ~ 85°C |
| Current - Supply | 7.5µA |
| Slew Rate | 0.1V/µs |
| Gain Bandwidth Product | 200 kHz |
| Current - Input Bias | 2 pA |
| Voltage - Input Offset | 1 mV |
| Supplier Device Package | TSOT-23-5 |
| Number of Circuits | 1 |
| Current - Output / Channel | 20 mA |
| -3db Bandwidth | 600 kHz |
| Voltage - Supply Span (Min) | 1.8 V |
| Voltage - Supply Span (Max) | 5.5 V |
