HF920AGSE-P
900V FIXED FREQUENCY OFF-LINE REManufacturer: Monolithic Power Systems Inc.
Categories: AC DC Converters, Offline Switches
Quality Control: Learn More
Converter Offline Flyback Topology 150kHz 8-SOIC-7A
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 16 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-SOIC (0.154"", 3.90mm Width), 7 Leads |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Duty Cycle | 83% |
| Frequency - Switching | 150kHz |
| Internal Switch(s) | Yes |
| Voltage - Breakdown | 900V |
| Output Isolation | Isolated |
| Topology | Flyback |
| Voltage - Supply (Vcc/Vdd) | 10V ~ 24V |
| Supplier Device Package | 8-SOIC-7A |
| Fault Protection | Current Limiting, Over Temperature, Over Voltage, Short Circuit, UVLO |
| Control Features | Frequency Control, Soft Start |
