5019516000
CONN FFC VERT 60POS 0.5MM SMDManufacturer: Molex
Categories: FFC, FPC (Flat Flexible) Connector Assemblies
Quality Control: Learn More
60 Position FFC, FPC Connector Contacts, Vertical - 1 Sided 0.020"" (0.50mm) Surface Mount
Additional Information
Series: Easy-On 501951RoHS Status: ROHS3 CompliantManufacturer Lead Time: 10 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tape & Reel (TR) |
| Contact Finish | Tin Bismuth |
| Voltage Rating | 50V |
| Mounting Type | Surface Mount |
| Number of Positions | 60 |
| Pitch | 0.020"" (0.50mm) |
| Operating Temperature | -25°C ~ 85°C |
| Termination | Solder |
| Height Above Board | 0.159"" (4.04mm) |
| Locking Feature | Flip Lock |
| Material Flammability Rating | UL94 V-0 |
| Actuator Material | Polyamide (PA9T), Nylon 9T, Glass Filled |
| Contact Material | Copper Alloy |
| FFC, FCB Thickness | 0.30mm |
| Housing Material | Liquid Crystal Polymer (LCP), Glass Filled |
| Cable End Type | Straight, Tapered |
| Flat Flex Type | FFC, FPC |
| Connector/Contact Type | Contacts, Vertical - 1 Sided |
