459713185
CONN HD ARRAY RCPT 240P SMD GOLDManufacturer: Molex
Categories: Arrays, Edge Type, Mezzanine (Board to Board)
Quality Control: Learn More
240 Position Connector High Density Array, Female Surface Mount Gold
Additional Information
Series: SEARAY 45971RoHS Status: ROHS3 CompliantManufacturer Lead Time: 16 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | Board Guide |
| Packaging | Tape & Reel (TR) |
| Connector Type | High Density Array, Female |
| Contact Finish | Gold |
| Mounting Type | Surface Mount |
| Number of Positions | 240 |
| Pitch | 0.050"" (1.27mm) |
| Height Above Board | 0.199"" (5.05mm) |
| Contact Finish Thickness | 30.0µin (0.76µm) |
| Mated Stacking Heights | 7mm, 7.5mm, 8mm, 8.5mm, 9.5mm, 10mm, 12mm |
| Number of Rows | 8 |
Request a Quote
