2N6764T1
MOSFET N-CH 100V 38A TO3Manufacturer: Microsemi Corporation
Categories: Single FETs, MOSFETs
Quality Control: Learn More
N-Channel 100 V 38A (Tc) 4W (Ta), 150W (Tc) Through Hole TO-3
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ActivePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | TO-204AE |
| Mounting Type | Through Hole |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Technology | MOSFET (Metal Oxide) |
| FET Type | N-Channel |
| Current - Continuous Drain (Id) @ 25°C | 38A (Tc) |
| Rds On (Max) @ Id, Vgs | 65mOhm @ 38A, 10V |
| FET Feature | - |
| Power Dissipation (Max) | 4W (Ta), 150W (Tc) |
| Vgs(th) (Max) @ Id | 4V @ 250µA |
| Supplier Device Package | TO-3 |
| Drive Voltage (Max Rds On, Min Rds On) | 10V |
| Vgs (Max) | ±20V |
| Drain to Source Voltage (Vdss) | 100 V |
| Gate Charge (Qg) (Max) @ Vgs | 125 nC @ 10 V |
Request a Quote
