LSM115J
DIODE SCHOTTKY 15V 1A DO214BAManufacturer: Microsemi Corporation
Categories: Single Diodes
Quality Control: Learn More
Microsemi Corporation's LSM115J is a Schottky diode offering 15V reverse voltage and 1A average rectified current. This component features a low forward voltage drop of 220mV at 1A and a reverse leakage of 10mA at 15V. Designed for efficient power rectification, its fast recovery time contributes to optimized circuit performance. The LSM115J is housed in a DO-214BA (SMC) surface-mount package, supplied on tape and reel. Its operational temperature range is -55°C to 100°C. This diode is suitable for applications in power supply design, automotive electronics, and telecommunications infrastructure.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | DO-214BA |
| Mounting Type | Surface Mount |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Technology | Schottky |
| Capacitance @ Vr, F | - |
| Current - Average Rectified (Io) | 1A |
| Supplier Device Package | DO-214BA |
| Operating Temperature - Junction | -55°C ~ 100°C |
| Voltage - DC Reverse (Vr) (Max) | 15 V |
| Voltage - Forward (Vf) (Max) @ If | 220 mV @ 1 A |
| Current - Reverse Leakage @ Vr | 10 mA @ 15 V |
Request a Quote
