MSTC130-16
MOD THYRISTOR DOUBLER 130A D1Manufacturer: Microsemi Corporation
Categories: SCRs - Modules
Quality Control: Learn More
Microsemi Corporation's MSTC130-16 is a robust SCR module featuring a series connection of two SCRs. This high-performance component offers an impressive 1.6 kV off-state voltage and a 130 A average on-state current. Designed for demanding applications, it boasts a 4700 A surge current capability at 50 Hz and a gate trigger current of 150 mA with a maximum gate trigger voltage of 3 V. The module operates within a temperature range of -40°C to 130°C (TJ) and is presented in a T2 package for efficient chassis mounting. This component is well-suited for power control applications in industrial motor drives, power supplies, and welding equipment.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDownload Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | T2 |
| Mounting Type | Chassis Mount |
| Operating Temperature | -40°C ~ 130°C (TJ) |
| Structure | Series Connection - All SCRs |
| Current - Hold (Ih) (Max) | 400 mA |
| Current - Gate Trigger (Igt) (Max) | 150 mA |
| Current - Non Rep. Surge 50, 60Hz (Itsm) | 4700A @ 50Hz |
| Number of SCRs, Diodes | 2 SCRs |
| Current - On State (It (AV)) (Max) | 130 A |
| Voltage - Gate Trigger (Vgt) (Max) | 3 V |
| Voltage - Off State | 1.6 kV |
