PC48F4400P0VB0EA
IC FLASH 512MBIT PAR 64EASYBGAManufacturer: Micron Technology Inc.
Categories: Memory
Quality Control: Learn More
Micron Technology Inc. presents the Axcell™ series PC48F4400P0VB0EA, a 512Mbit NOR Flash memory integrated circuit. This component features a parallel interface with a clock frequency of 52 MHz and an access time of 100 ns. The memory organization is 32M x 16, providing efficient data handling. Designed for surface mount applications, it utilizes a 64-EasyBGA (10x13) package, also known as 64-LBGA. The device operates with a supply voltage range of 1.7V to 2V and supports a temperature range of -40°C to 85°C (TC). This non-volatile memory technology is suitable for demanding applications in the automotive and industrial sectors.
Additional Information
Series: Axcell™RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDownload Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 64-LBGA |
| Mounting Type | Surface Mount |
| Memory Size | 512Mbit |
| Memory Type | Non-Volatile |
| Operating Temperature | -40°C ~ 85°C (TC) |
| Voltage - Supply | 1.7V ~ 2V |
| Technology | FLASH - NOR |
| Clock Frequency | 52 MHz |
| Memory Format | FLASH |
| Supplier Device Package | 64-EasyBGA (10x13) |
| Write Cycle Time - Word, Page | 100ns |
| Memory Interface | Parallel |
| Access Time | 100 ns |
| Memory Organization | 32M x 16 |
| Programmable | Not Verified |
