MT48H8M32LFF5-8 IT
IC DRAM 256MBIT PAR 90VFBGAManufacturer: Micron Technology Inc.
Categories: Memory
Quality Control: Learn More
Micron Technology Inc. MT48H8M32LFF5-8-IT is a 256Mbit Low Power Double Data Rate (LPSDR) Synchronous Dynamic Random-Access Memory (SDRAM) component. This device offers a parallel interface with a memory organization of 8M x 32, providing a total capacity of 256 Megabits. Operating at a clock frequency of 125 MHz, it features an access time of 7 ns and a write cycle time of 15 ns. The MT48H8M32LFF5-8-IT is housed in a 90-VFBGA (8x13) surface mount package and operates within a supply voltage range of 1.7V to 1.95V. Its operating temperature range is -40°C to 85°C (TA). This memory component is suitable for applications in consumer electronics and industrial systems requiring high-performance, low-power memory solutions.
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: DiscontinuedPackaging: BoxDownload Free CAD Model:
Technical Details:
| Packaging | Box |
| Package / Case | 90-VFBGA |
| Mounting Type | Surface Mount |
| Memory Size | 256Mbit |
| Memory Type | Volatile |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Voltage - Supply | 1.7V ~ 1.95V |
| Technology | SDRAM - Mobile LPSDR |
| Clock Frequency | 125 MHz |
| Memory Format | DRAM |
| Supplier Device Package | 90-VFBGA (8x13) |
| Write Cycle Time - Word, Page | 15ns |
| Memory Interface | Parallel |
| Access Time | 7 ns |
| Memory Organization | 8M x 32 |
| Programmable | Not Verified |
Request a Quote
