MT44K32M18RB-093E:B
IC DRAM 576MBIT PAR 168BGAManufacturer: Micron Technology Inc.
Categories: Memory
Quality Control: Learn More
Micron Technology Inc. MT44K32M18RB-093E-B is a 576Mbit DRAM memory IC featuring a parallel interface with a 32M x 18 organization. This component operates at a clock frequency of 1.066 GHz, offering an access time of 8 ns. The device utilizes a 168-BGA (13.5x13.5) package for surface mounting and operates within a supply voltage range of 1.28V to 1.42V. Typical applications for this memory solution span the automotive, industrial, and networking sectors. The operating temperature range for this component is 0°C to 95°C (TC).
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 168-TBGA |
| Mounting Type | Surface Mount |
| Memory Size | 576Mbit |
| Memory Type | Volatile |
| Operating Temperature | 0°C ~ 95°C (TC) |
| Voltage - Supply | 1.28V ~ 1.42V |
| Technology | DRAM |
| Clock Frequency | 1.066 GHz |
| Memory Format | DRAM |
| Supplier Device Package | 168-BGA (13.5x13.5) |
| Write Cycle Time - Word, Page | - |
| Memory Interface | Parallel |
| Access Time | 8 ns |
| Memory Organization | 32M x 18 |
| Programmable | Not Verified |
Request a Quote
