M58LR128KT85ZB5E
IC FLASH 128MBIT PAR 56VFBGAManufacturer: Micron Technology Inc.
Categories: Memory
Quality Control: Learn More
Micron Technology Inc. NOR Flash memory, part number M58LR128KT85ZB5E, offers 128Mbit of non-volatile storage. This component features a parallel interface with a clock frequency of 66 MHz and an access time of 85 ns. The memory organization is 8M x 16. It operates within a supply voltage range of 1.7V to 2V and is housed in a 56-VFBGA package with dimensions of 7.7x9. The operating temperature range is -30°C to 85°C. This NOR Flash memory is suitable for applications in automotive, industrial, and communication systems requiring reliable, high-speed data storage.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDownload Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 56-VFBGA |
| Mounting Type | Surface Mount |
| Memory Size | 128Mbit |
| Memory Type | Non-Volatile |
| Operating Temperature | -30°C ~ 85°C (TA) |
| Voltage - Supply | 1.7V ~ 2V |
| Technology | FLASH - NOR |
| Clock Frequency | 66 MHz |
| Memory Format | FLASH |
| Supplier Device Package | 56-VFBGA (7.7x9) |
| Write Cycle Time - Word, Page | 85ns |
| Memory Interface | Parallel |
| Access Time | 85 ns |
| Memory Organization | 8M x 16 |
| Programmable | Not Verified |
