MSMCJ48A
TVS DIODE 48VWM 77.4VC DO214ABManufacturer: Microchip Technology
Categories: TVS Diodes
Quality Control: Learn More
The Microchip Technology MSMCJ48A is a unidirectional Transient Voltage Suppressor (TVS) diode, designed for surface mount applications within the DO-214AB (SMCJ) package. This component offers a reverse standoff voltage of 48V and a breakdown voltage of 53.3V minimum. It features a maximum clamping voltage of 77.4V at a peak pulse current of 19.4A (10/1000µs), providing 1500W of peak pulse power dissipation. Qualified to MIL-PRF-19500 and designed for military applications, the MSMCJ48A operates across a temperature range of -65°C to 150°C. This device is suitable for general-purpose protection applications where robust transient voltage suppression is required.
Additional Information
Series: -RoHS Status: RoHS Compliant By ExemptionManufacturer Lead Time: 40 week(s)Product Status: ActivePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | DO-214AB, SMC |
| Mounting Type | Surface Mount |
| Type | Zener |
| Operating Temperature | -65°C ~ 150°C (TJ) |
| Applications | General Purpose |
| Capacitance @ Frequency | - |
| Current - Peak Pulse (10/1000µs) | 19.4A |
| Voltage - Reverse Standoff (Typ) | 48V |
| Supplier Device Package | DO-214AB (SMCJ) |
| Unidirectional Channels | 1 |
| Voltage - Breakdown (Min) | 53.3V |
| Voltage - Clamping (Max) @ Ipp | 77.4V |
| Power - Peak Pulse | 1500W (1.5kW) |
| Power Line Protection | No |
| Grade | Military |
| Qualification | MIL-PRF-19500 |
