MSMBJSAC15E3
TVS DIODE 15VWM 23.6VC SMBJManufacturer: Microchip Technology
Categories: TVS Diodes
Quality Control: Learn More
Microchip Technology MSMBJSAC15E3, a TVS Diode, offers robust transient voltage suppression. This component is designed for surface mount applications within the DO-214AA (SMBJ) package. It features a reverse standoff voltage of 15V and a breakdown voltage minimum of 16.7V. The diode provides a 23.6V clamping voltage at a peak pulse current of 20A (Ipp 10/1000µs), with a peak pulse power capability of 500W. Additional specifications include a capacitance of 30pF at 1MHz, a unidirectional channel, and an operating temperature range of -65°C to 150°C. This device meets MIL-PRF-19500 qualification, making it suitable for demanding applications in industries requiring high reliability, such as aerospace and defense.
Additional Information
Series: -RoHS Status: RoHS Compliant By ExemptionManufacturer Lead Time: 40 week(s)Product Status: ActivePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | DO-214AA, SMB |
| Mounting Type | Surface Mount |
| Type | Zener |
| Operating Temperature | -65°C ~ 150°C (TJ) |
| Applications | General Purpose |
| Capacitance @ Frequency | 30pF @ 1MHz |
| Current - Peak Pulse (10/1000µs) | 20A |
| Voltage - Reverse Standoff (Typ) | 15V |
| Supplier Device Package | DO-214AA (SMBJ) |
| Unidirectional Channels | 1 |
| Voltage - Breakdown (Min) | 16.7V |
| Voltage - Clamping (Max) @ Ipp | 23.6V |
| Power - Peak Pulse | 500W |
| Power Line Protection | No |
| Grade | Military |
| Qualification | MIL-PRF-19500 |
