JANS1N6122A/TR
BI-DIRECTIONAL TVSManufacturer: Microchip Technology
Categories: TVS Diodes
Quality Control: Learn More
Microchip Technology JANS1N6122A-TR is a military-grade, bi-directional Transient Voltage Suppressor (TVS) diode designed for robust surge protection. This component features a peak pulse current capability of 7.7A (10/1000µs) and a maximum clamping voltage of 64.6V at this current. The device offers a minimum breakdown voltage of 44.7V and a typical reverse standoff voltage of 35.8V. Rated for a peak pulse power of 500W, it operates across a wide junction temperature range of -55°C to 175°C. The JANS1N6122A-TR is qualified to MIL-PRF-19500/516 and is supplied in a B, Axial package, presented in Tape & Reel (TR) packaging for efficient automated assembly. Its bidirectional design makes it suitable for general-purpose applications requiring protection against voltage transients.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: 32 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | B, Axial |
| Mounting Type | Through Hole |
| Type | Zener |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Applications | General Purpose |
| Capacitance @ Frequency | - |
| Current - Peak Pulse (10/1000µs) | 7.7A |
| Voltage - Reverse Standoff (Typ) | 35.8V |
| Supplier Device Package | B, Axial |
| Bidirectional Channels | 1 |
| Voltage - Breakdown (Min) | 44.7V |
| Voltage - Clamping (Max) @ Ipp | 64.6V |
| Power - Peak Pulse | 500W |
| Power Line Protection | No |
| Grade | Military |
| Qualification | MIL-PRF-19500/516 |
