JAN1N4960US
DIODE ZENER 12V 5W D5BManufacturer: Microchip Technology
Categories: Single Zener Diodes
Quality Control: Learn More
Microchip Technology JAN1N4960US is a 12V Zener diode rated for 5W with a ±5% tolerance. This military-grade component, qualified to MIL-PRF-19500/356, features a low reverse leakage of 10 µA at 9.1V and a maximum Zener impedance of 2.5 Ohms. It is supplied in a D-5B package, also known as SQ-MELF, E, for surface mounting. The device operates across a wide temperature range of -65°C to 175°C. The JAN1N4960US is suitable for applications in aerospace, defense, and high-reliability industrial systems requiring robust voltage regulation and power handling. Forward voltage is specified at 1.5V maximum at 1A.
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: 28 week(s)Product Status: ActivePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Tolerance | ±5% |
| Packaging | Bulk |
| Package / Case | SQ-MELF, E |
| Mounting Type | Surface Mount |
| Operating Temperature | -65°C ~ 175°C |
| Voltage - Zener (Nom) (Vz) | 12 V |
| Impedance (Max) (Zzt) | 2.5 Ohms |
| Supplier Device Package | D-5B |
| Grade | Military |
| Power - Max | 5 W |
| Voltage - Forward (Vf) (Max) @ If | 1.5 V @ 1 A |
| Current - Reverse Leakage @ Vr | 10 µA @ 9.1 V |
| Qualification | MIL-PRF-19500/356 |
