APT66M60B2
MOSFET N-CH 600V 70A T-MAXManufacturer: Microchip Technology
Categories: Single FETs, MOSFETs
Quality Control: Learn More
N-Channel 600 V 70A (Tc) 1135W (Tc) Through Hole T-MAX™ [B2]
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 26 week(s)Product Status: ActivePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tube |
| Package / Case | TO-247-3 Variant |
| Mounting Type | Through Hole |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Technology | MOSFET (Metal Oxide) |
| FET Type | N-Channel |
| Current - Continuous Drain (Id) @ 25°C | 70A (Tc) |
| Rds On (Max) @ Id, Vgs | 100mOhm @ 33A, 10V |
| FET Feature | - |
| Power Dissipation (Max) | 1135W (Tc) |
| Vgs(th) (Max) @ Id | 5V @ 2.5mA |
| Supplier Device Package | T-MAX™ [B2] |
| Drive Voltage (Max Rds On, Min Rds On) | 10V |
| Vgs (Max) | ±30V |
| Drain to Source Voltage (Vdss) | 600 V |
| Gate Charge (Qg) (Max) @ Vgs | 330 nC @ 10 V |
| Input Capacitance (Ciss) (Max) @ Vds | 13190 pF @ 25 V |
Request a Quote
