R42140
DIODE GP REV 1.4KV 125A DO205AAManufacturer: Microchip Technology
Categories: Single Diodes
Quality Control: Learn More
Microchip Technology R42140 is a general-purpose diode featuring a robust DO-205AA (DO-8) stud mount package. This component is engineered for high-voltage, high-current applications, boasting a maximum DC reverse voltage (Vr) of 1400 V and an average rectified forward current (Io) of 125A. Its forward voltage drop (Vf) is a maximum of 1.2 V at 200A. The diode exhibits a low reverse leakage current of 50 µA at its rated Vr. Operating across a wide junction temperature range of -65°C to 200°C, the R42140 utilizes standard recovery technology with a recovery time exceeding 500ns for currents greater than 200mA. This device is suitable for power supply rectification, motor control, and industrial power conversion systems.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: 29 week(s)Product Status: ActivePackaging: BulkDownload Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | DO-205AA, DO-8, Stud |
| Mounting Type | Stud Mount |
| Speed | Standard Recovery >500ns, > 200mA (Io) |
| Technology | Standard, Reverse Polarity |
| Capacitance @ Vr, F | - |
| Current - Average Rectified (Io) | 125A |
| Supplier Device Package | DO-205AA (DO-8) |
| Operating Temperature - Junction | -65°C ~ 200°C |
| Voltage - DC Reverse (Vr) (Max) | 1400 V |
| Voltage - Forward (Vf) (Max) @ If | 1.2 V @ 200 A |
| Current - Reverse Leakage @ Vr | 50 µA @ 1400 V |
