1N3659
DIODE GEN PURP 50V 35A DO21Manufacturer: Microchip Technology
Categories: Single Diodes
Quality Control: Learn More
Microchip Technology's 1N3659 is a general-purpose rectifier diode with a 50V reverse voltage rating and a 35A average rectified current capability. This component, supplied in Bulk packaging within a DO-208AA (DO-21) press-fit package, features a standard recovery time exceeding 500ns. The forward voltage drop is a maximum of 1.1V at 35A, with a reverse leakage current of 10 µA at 50V. Operating across a junction temperature range of -65°C to 175°C, this diode is suitable for power supply rectification and general power switching applications in industrial and automotive sectors. Its press-fit mounting facilitates efficient thermal management in high-current designs.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: 29 week(s)Product Status: ActivePackaging: BulkDownload Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | DO-208AA |
| Mounting Type | Press Fit |
| Speed | Standard Recovery >500ns, > 200mA (Io) |
| Technology | Standard |
| Capacitance @ Vr, F | - |
| Current - Average Rectified (Io) | 35A |
| Supplier Device Package | DO-21 |
| Operating Temperature - Junction | -65°C ~ 175°C |
| Voltage - DC Reverse (Vr) (Max) | 50 V |
| Voltage - Forward (Vf) (Max) @ If | 1.1 V @ 35 A |
| Current - Reverse Leakage @ Vr | 10 µA @ 50 V |
