2N3741A
PNP TRANSISTORManufacturer: Microchip Technology
Categories: Single Bipolar Transistors
Quality Control: Learn More
Microchip Technology's 2N3741A is a high-performance PNP bipolar junction transistor (BJT) designed for demanding applications. This through-hole component, housed in a TO-66 (TO-213AA) package, offers a maximum collector current of 4A and a collector-emitter breakdown voltage of 80V. It features a transition frequency of 3MHz and a maximum power dissipation of 25W, making it suitable for power switching and amplification circuits. Key electrical characteristics include a Vce(sat) of 600mV at 125mA/1A and a minimum DC current gain (hFE) of 40 at 100mA/1V. The 2N3741A operates across a wide temperature range from -65°C to 200°C. This device finds application in industrial control, power management, and audio amplification systems.
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: 36 week(s)Product Status: ActivePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | TO-213AA, TO-66-2 |
| Mounting Type | Through Hole |
| Transistor Type | PNP |
| Operating Temperature | -65°C ~ 200°C (TJ) |
| Vce Saturation (Max) @ Ib, Ic | 600mV @ 125mA, 1A |
| Current - Collector Cutoff (Max) | 1µA |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 40 @ 100mA, 1V |
| Frequency - Transition | 3MHz |
| Supplier Device Package | TO-66 (TO-213AA) |
| Current - Collector (Ic) (Max) | 4 A |
| Voltage - Collector Emitter Breakdown (Max) | 80 V |
| Power - Max | 25 W |
