MRF24WN0MA-I/RM100
RF TXRX MOD WIFI TH SMDManufacturer: Microchip Technology
Categories: RF Transceiver Modules and Modems
Quality Control: Learn More
Microchip Technology's MRF24WN0MA-I-RM100 is a 2.4GHz WiFi 802.11b/g/n transceiver module. This surface mount device features an integrated trace antenna and supports BPSK, CCK, DSSS, QAM, and QPSK modulation schemes. With a data rate up to 54Mbps, it operates across the 2.4GHz frequency band. Transmit power is rated at 20.7dBm, and receiver sensitivity is -94dBm. Power consumption ranges from 61mA to 73mA during reception and 196mA to 248mA during transmission. The module utilizes SPI for serial communication and is designed for operation within an industrial temperature range of -40°C to 85°C. The MRF24WN0MA-I-RM100 is suitable for applications in industrial automation, consumer electronics, and IoT devices. It is supplied in Tray packaging.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 37-SMD Module |
| Sensitivity | -94dBm |
| Mounting Type | Surface Mount |
| Frequency | 2.4GHz |
| Memory Size | - |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 3.15V ~ 3.45V |
| Power - Output | 20.7dBm |
| Data Rate | 54Mbps |
| Protocol | 802.11b/g/n |
| Current - Receiving | 61mA ~ 73mA |
| Current - Transmitting | 196mA ~ 248mA |
| Antenna Type | Integrated, Trace |
| Utilized IC / Part | - |
| Modulation | BPSK, CCK, DSSS, QAM, QPSK |
| RF Family/Standard | WiFi |
| Serial Interfaces | SPI |
| Programmable | Not Verified |
