MRF24WG0MA-I/RM

RF TXRX MOD WIFI TH SMD

Manufacturer: Microchip Technology

Categories: RF Transceiver Modules and Modems

Quality Control: Learn More

The Microchip Technology MRF24WG0MA-I-RM is a surface mount WiFi 802.11b/g transceiver module operating in the 2.4GHz band. This module integrates a trace antenna for compact designs. It supports DSSS and OFDM modulation schemes, offering data rates up to 11Mbps. Transmit power is rated at 18dBm, with receiver sensitivity at -95dBm. Operating current consumption is 156mA for receiving and 226mA to 237mA for transmitting. The module interfaces via SPI and requires a supply voltage between 2.8V and 3.6V. Its operating temperature range is -40°C to 85°C. This component is commonly utilized in industrial automation, consumer electronics, and IoT applications.

Additional Information

Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:
Technical Details:
PackagingTray
Package / Case36-SMD Module
Sensitivity-95dBm
Mounting TypeSurface Mount
Frequency2.4GHz
Memory Size-
Operating Temperature-40°C ~ 85°C
Voltage - Supply2.8V ~ 3.6V
Power - Output18dBm
Data Rate11Mbps
Protocol802.11b/g
Current - Receiving156mA
Current - Transmitting226mA ~ 237mA
Antenna TypeIntegrated, Trace
Utilized IC / Part-
ModulationDSSS, OFDM
RF Family/StandardWiFi
Serial InterfacesSPI
ProgrammableNot Verified
