T2801-PLH
IC RF TXRX ISM>1GHZ 48QFNManufacturer: Microchip Technology
Categories: RF Transceiver ICs
Quality Control: Learn More
Microchip Technology T2801-PLH is a transmit-only RF transceiver IC operating in the general ISM band above 1GHz, specifically at 1.9GHz. This component is housed in a 48-VFQFN exposed pad package, designed for surface mounting and supplied on tape and reel. Key operational parameters include a supply voltage range of 3V to 4.6V, with typical transmit currents of 54mA to 58mA and a receive current of 85mA. Output power is rated at 0dBm. The T2801-PLH utilizes SPI serial interfaces for communication. This device is suitable for applications in wireless communication systems, including IoT devices and industrial automation.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 48-VFQFN Exposed Pad |
| Sensitivity | - |
| Mounting Type | Surface Mount |
| Frequency | 1.9GHz |
| Memory Size | - |
| Type | TxRx Only |
| Operating Temperature | -25°C ~ 85°C |
| Voltage - Supply | 3V ~ 4.6V |
| Power - Output | 0dBm |
| Protocol | - |
| Current - Receiving | 85mA |
| Data Rate (Max) | - |
| Current - Transmitting | 54mA ~ 58mA |
| Supplier Device Package | 48-QFN (7x7) |
| Modulation | - |
| RF Family/Standard | General ISM > 1GHz |
| Serial Interfaces | SPI |
| Programmable | Not Verified |
