ATMEGA128RFA1-ZU
IC RF TXRX+MCU 802.15.4 64QFNManufacturer: Microchip Technology
Categories: RF Transceiver ICs
Quality Control: Learn More
IC RF TxRx + MCU 802.15.4 6LoWPAN, Zigbee® 2.4GHz 64-VFQFN Exposed Pad
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 8 week(s)Product Status: ActivePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 64-VFQFN Exposed Pad |
| Sensitivity | -100dBm |
| Mounting Type | Surface Mount |
| Frequency | 2.4GHz |
| Memory Size | 128kB Flash, 4kB EEPROM, 16kB SRAM |
| Type | TxRx + MCU |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 1.8V ~ 3.6V |
| Power - Output | 3.5dBm |
| Protocol | 6LoWPAN, Zigbee® |
| Current - Receiving | 12mA ~ 12.5mA |
| Data Rate (Max) | 2Mbps |
| Current - Transmitting | 8mA ~ 14.5mA |
| Supplier Device Package | 64-QFN (9x9) |
| GPIO | 38 |
| Modulation | O-QPSK |
| RF Family/Standard | 802.15.4 |
| Serial Interfaces | I2C, JTAG, SPI, USART |
| Programmable | Not Verified |
Request a Quote
