ATA8520D-GHQW
IC RF TXRX+MCU ISM<1GHZ 32VQFNManufacturer: Microchip Technology
Categories: RF Transceiver ICs
Quality Control: Learn More
The Microchip Technology ATA8520D-GHQW is a highly integrated RF transceiver and microcontroller solution designed for low-power, sub-GHz wireless applications. This device features a robust radio front-end supporting General ISM < 1GHz bands, specifically optimized for the 868MHz frequency. It incorporates advanced modulation schemes, including DBSPK and GFSK, achieving a maximum data rate of 600bps. The transceiver boasts impressive sensitivity of -121.5dBm and provides adjustable transmit power up to 14dBm.
Integrated within the 32-VQFN (5x5) exposed pad package, the ATA8520D-GHQW houses a capable microcontroller, enabling standalone operation for a variety of embedded wireless tasks. It supports SPI serial interfaces for communication and control. Operating across a voltage range of 1.9V to 3.6V and 2.4V to 5.5V, this component exhibits low power consumption, with typical receiving current of 10.4mA and transmitting current around 31.8mA to 32.7mA. Its design makes it suitable for applications in smart metering, industrial automation, and wireless sensor networks. The device is supplied on tape and reel for efficient surface mount assembly.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 32-VFQFN Exposed Pad |
| Sensitivity | -121.5dBm |
| Mounting Type | Surface Mount |
| Frequency | 868MHz |
| Memory Size | - |
| Type | TxRx + MCU |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 1.9V ~ 3.6V, 2.4V ~ 5.5V |
| Power - Output | 14dBm |
| Protocol | SIGFOX™ |
| Current - Receiving | 10.4mA |
| Data Rate (Max) | 600bps |
| Current - Transmitting | 31.8mA ~ 32.7mA |
| Supplier Device Package | 32-VQFN (5x5) |
| Modulation | DBSPK, GFSK |
| RF Family/Standard | General ISM < 1GHz |
| Serial Interfaces | SPI |
| Programmable | Not Verified |
Request a Quote
