ATA5824C-PLQW
IC RF TXRX ISM<1GHZ 48VQFNManufacturer: Microchip Technology
Categories: RF Transceiver ICs
Quality Control: Learn More
Microchip Technology ATA5824C-PLQW is a highly integrated RF transmitter/receiver IC designed for General ISM band applications below 1GHz. This component operates at 434MHz and supports ASK and FSK modulation schemes with a maximum data rate of 20kbps. The device features a robust sensitivity of -116dBm and an output power of up to 10dBm. Power consumption is efficient, with a receiving current of 10.5mA and transmitting currents ranging from 6.95mA to 15.8mA. The ATA5824C-PLQW is packaged in a 48-VFQFN exposed pad (7x7mm) for surface mounting and is supplied on tape and reel. It interfaces via SPI and operates across a wide temperature range of -40°C to 105°C, with supply voltages from 2.15V to 3.6V and 4.4V to 5.25V. This device finds application in automotive, industrial, and consumer electronics sectors requiring reliable wireless communication.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 48-VFQFN Exposed Pad |
| Sensitivity | -116dBm |
| Mounting Type | Surface Mount |
| Frequency | 434MHz |
| Memory Size | - |
| Type | TxRx Only |
| Operating Temperature | -40°C ~ 105°C |
| Voltage - Supply | 2.15V ~ 3.6V, 4.4V ~ 5.25V |
| Power - Output | 10dBm |
| Protocol | - |
| Current - Receiving | 10.5mA |
| Data Rate (Max) | 20kbps |
| Current - Transmitting | 6.95mA ~ 15.8mA |
| Supplier Device Package | 48-VQFN (7x7) |
| Modulation | ASK, FSK |
| RF Family/Standard | General ISM < 1GHz |
| Serial Interfaces | SPI |
| Programmable | Not Verified |
