T5743P3-TGQ
RF RX ASK/FSK 300-450MHZ 20SOICManufacturer: Microchip Technology
Categories: RF Receivers
Quality Control: Learn More
The Microchip Technology T5743P3-TGQ is a highly sensitive RF receiver designed for ASK and FSK modulation schemes across the 300MHz to 450MHz frequency band. Featuring a sensitivity of -108dBm and a maximum data rate of 10kBaud, this component is ideal for general-purpose data transmission systems. It operates with a supply voltage range of 4.5V to 5.5V and a receiving current of 30mA. The T5743P3-TGQ is packaged in a 20-SOIC (0.295", 7.50mm Width) and utilizes a PCB, Surface Mount antenna connector. This device is commonly found in applications requiring reliable wireless communication, including industrial automation and remote control systems. It is supplied in Tape & Reel (TR) packaging.
Additional Information
Series: -RoHS Status: RoHS Compliant By ExemptionManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tape & Reel (TR) |
| Package / Case | 20-SOIC (0.295"", 7.50mm Width) |
| Sensitivity | -108dBm |
| Mounting Type | Surface Mount |
| Frequency | 300MHz ~ 450MHz |
| Memory Size | - |
| Modulation or Protocol | ASK, FSK |
| Data Interface | PCB, Surface Mount |
| Operating Temperature | -40°C ~ 105°C |
| Voltage - Supply | 4.5V ~ 5.5V |
| Applications | General Purpose Data Transmission Systems |
| Current - Receiving | 30mA |
| Data Rate (Max) | 10kBaud |
| Antenna Connector | PCB, Surface Mount |
| Supplier Device Package | 20-SOIC |
