MICRF022BM-FS48-TR
RF RX ASK/OOK 300-440MHZ 8SOICManufacturer: Microchip Technology
Categories: RF Receivers
Quality Control: Learn More
The Microchip Technology MICRF022BM-FS48-TR is a highly integrated RF receiver designed for ASK and OOK modulation schemes, operating within the 300MHz to 440MHz frequency band. This component offers a sensitivity of -97dBm at a maximum data rate of 10kbps, making it suitable for applications requiring robust wireless communication. Engineered for surface-mount applications, it utilizes a standard 8-SOIC package and connects to the antenna via a PCB trace. The device operates efficiently with a typical receiving current of 2.2mA and a supply voltage range of 4.75V to 5.5V. Its operational temperature range is -40°C to 85°C. This receiver is commonly employed in Remote Keyless Entry (RKE) systems and other low-power, short-range wireless data transmission applications. The part is supplied in a Tape & Reel (TR) package for automated assembly.
Additional Information
Series: -RoHS Status: RoHS Compliant By ExemptionManufacturer Lead Time: No lead time information availableProduct Status: DiscontinuedPackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-SOIC (0.154"", 3.90mm Width) |
| Sensitivity | -97dBm |
| Mounting Type | Surface Mount |
| Frequency | 300MHz ~ 440MHz |
| Memory Size | - |
| Modulation or Protocol | ASK, OOK |
| Data Interface | PCB, Surface Mount |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 4.75V ~ 5.5V |
| Applications | RKE |
| Current - Receiving | 2.2mA |
| Data Rate (Max) | 10kbps |
| Antenna Connector | PCB, Surface Mount |
| Supplier Device Package | 8-SOIC |
